Overview

Keep your factory air clean and safe with our high-efficiency bag dust collector.

A. Remove dust efficiently – coarse and fine particles are captured for stable purification

B. Continuous operation – automated compressed air cleaning keeps your system running smoothly

C. Easy to maintain – durable filter bags and metal frames for long-term reliability

D. Flexible application – ideal for chemical, metal, electronics, and other industrial processes

How the Industrial Bag Dust Collector Works

Your dust-laden gas enters the collector, where coarse particles settle in the ash hopper, and fine dust is captured on the surface of filter bags. This ensures that clean air is discharged safely while dust accumulates on the bags.

To maintain continuous operation, our PLC-controlled pulse cleaning system periodically sprays compressed air to remove the dust from each filter bag without stopping the rest of the system. The removed dust falls into the ash hopper and is discharged automatically.

This process ensures efficient filtration, stable airflow, and minimal maintenance, keeping your production line running smoothly.

Soot cleaning

When the dust layer on your filter bags builds up and equipment resistance reaches the set limit, the automatic cleaning system activates.

Step 1 – Isolate the chamber: The air supply to the chamber is cut off to ensure effective cleaning.
Step 2 – Pulse cleaning: Compressed air is released rapidly into the filter bag, causing it to expand and vibrate, dislodging dust from the bag surface.
Step 3 – Dust removal: The loosened dust falls into the ash hopper and is centrally discharged through the ash discharge system.
Step 4 – Cycle continues: Each chamber is cleaned in sequence while the other chambers continue filtering, ensuring continuous operation.

This process allows you to maintain efficient dust removal, stable airflow, and minimal downtime while keeping the system running safely and reliably.

Features

Efficiently capture dust without stopping your production.

A. Reliable filtration: Coarse dust settles in the ash hopper, fine dust is trapped on the filter bags, ensuring clean air output.

B. Automated pulse cleaning: Each filter bag is cleaned in sequence while the system keeps running, so you don’t lose production time.

C. Longer service life: Reduced wear on bags and valves extends maintenance intervals, lowering your operating costs.

D. Safe and easy bag handling: Filter bags can be replaced in a single chamber without shutting down the system, improving worker safety and convenience.

E. Used in: chemical, metal, electronics, cement, and other industrial processes where dust removal is critical.

Get a customized solution for your factory – contact us today.

Application industry

Our industrial bag dust collector is designed for high-temperature, high-volume exhaust and provides efficient, reliable dust removal for your operations.

Typical applications include:

A. Steel & ferroalloy plants – electric furnace and flue gas purification

B. Cement plants – rotary kiln inlet/outlet dust removal

C. Power plants – coal-fired boiler exhaust dust control

D. Aluminum, carbon black, and smelters – high-temperature flue gas purification

E. Waste incineration facilities – dust and particulate control

With low emissions, low energy consumption, and compact footprint, it ensures stable operation even in the toughest industrial environments.

Why Choose Us

A. Full cycle professional services from design to commissioning

B. 40+ patented technologies & strong R&D team

C. ISO certified quality and international compliance

D. High efficiency with cost?effective solutions

E. Fast after sales support and maintenance

F. Proven solutions across multiple industrial sectors
